Turck’s TBIL-EMN-16DXP expands IO-Link connectivity with 16 universal digital PNP channels in a compact, machine-mountable housing. Each port supports input or output functionality without configuration, reducing commissioning time and inventory complexity. IO-Link V1.1 Class A communication delivers diagnostics for short circuits and supply voltage issues. Designed for direct field installation, the rugged IP67/IP69K module operates from –25°C to +60°C and reduces cost per I/O point in distributed automation systems.
FEATURES:
- 16 universal digital PNP channels (inputs and outputs).
- IO-Link V1.1 Class A interface (COM2, 38.4 kbps).
- Two digital channels per slot with no configuration required.
- 24 VDC supply (18–30 VDC range) with short-circuit protection.
- Output current: 0.35 A per channel (4 A total).
- Integrated IO-Link diagnostics for short circuit and supply monitoring.
- Compact 54 × 150 × 27.4 mm housing, IP67/IP69K rated.
- ATEX Zone 2/22 approved; –25°C to +60°C operating range.
Turck TBIL-EMN-16DXP compact IO-Link hub
